2 Micron SWIR InGaAs Balanced Photoreceiver with 150 MHz Bandwidth

Contact Us and PDF Datasheet Request
Datasheet Request Contact Us

Description:

A low-noise, 20 dB gain balanced photoreceiver for wavelengths from 1.2 to 2.2 micron with over 150 MHz bandwidth for LIDAR or eye-safe free-space applications. The R205M consists of matched InGaAs/InP photodiodes and a transimpedance amplifier with low electrical-return-loss for improved link performance. The R205M may be used in coherent-lightwave link designs to eliminate DC intensity noise, effectively using all of the link signal and local oscillator power. Losses due to mixing in single port receivers are eliminated and the link is able to operate near the shot-noise limit. The component module is packaged for use in the Lab Buddy, protecting the fiber and photoreceiver from accidental damage in the lab due to mishandling or incorrect power supplies.

2 Micron SWIR InGaAs Balanced Photoreceiver with 150 MHz Bandwidth in Lab Buddy

Figure1: DSCR-205M

DSC-R205M - Typical single channel RF response curves at 1550 nm

Figure2: Typical single channel RF response curves at 1550 nm

Salient Features:
  • Spectral wavelength range of 1.2 to 2.2 um
  • Balanced InGaAs PIN photodiodes
  • 20 dB gain post amplifier

Applications:

  • LIDAR at 2 um
  • Eye-safe free-space links
  • Eliminate laser RIN

Available Models:

  • DSC-R205M - Long Wavelength (2um) Balanced Photoreceivers with 150 MHz Bandwidth
